Male 60 deg cone connector
Product category: JIS standard Hydraulic fittings to various adapters
JIS thread size chart is produce as per : BSPP Threads: ISO 228-1 G, JIS B0202; BSPT Threads: ISO 7/1, JIS B0203.
JIS fittings is designed with 30°flare and 60°cone connections to hose ends, also used as hose adapters.
To pipe thread types: JIS B2351 port, Npt, SAE ORB adapter etc.
1S JIS GAS MALE 60°CONE specifications as follows:
PART NO. | THREAD | DIMENSIONS | ||||||
E | F | A | B | L | S1 | |||
1S-02 | G1/8"X28 | G1/8"X28 | 12 | 12 | 30 | 14 | ||
1S-04 | G1/4"X19 | G1/4"X19 | 16 | 16 | 38 | 17 | ||
1S-06 | G3/8"X19 | G3/8"X19 | 18 | 18 | 42 | 19 | ||
1S-08 | G1/2"X14 | G1/2"X14 | 20 | 20 | 48 | 22 | ||
1S-12 | G3/4"X14 | G3/4"X14 | 22 | 22 | 54 | 30 | ||
1S-16 | G1"X11 | G1"X11 | 24 | 24 | 59 | 36 | ||
1S-20 | G1.1/4"X11 | G1.1/4"X11 | 27 | 27 | 67 | 46 | ||
1S-24 | G1.1/2"X11 | G1.1/2"X11 | 27 | 27 | 69 | 50 | ||
1S-32 | G2"X11 | G2"X11 | 30 | 30 | 77 | 65 | ||
