Hydraulic tube fittings and adapters offer reliable, leak-free connections.
It is often found in hydraulic tubing systems, hydraulic steel tube is made of cold-drawn, and annealed seamless low-carbon steel, pressure tubing for use as a hydraulic line.
JIayuan offers different types of hydraulic tube fittings, to connect different flare tubings as follows:
- Flared tube end with 45° SAE style, 37° AN style, and 37° JIC style Flare tube fittings.
- Face Seal tube end with copper brazed weld-on tube sleeve or flat face by cold metal working.
- Flareless tube end with cutting ring bite in tube to tube connectors.
to match with the tube connector as follows:
- SAE tube fittings, AN tube fittings, and JIC tube fittings.
- ORFS tube fittings.
- Metric tube fittings
From hydraulic tube end to port connections as follows:
- Tube to SAE flange port
- Tube to SAE ORB J1926-1 port
- Tube to BSPP DIN 3852-2 port
- Tube to Metric DIN 3852-1 port
- Tube to Metric ISO 6149-1 port
- Tube to BSP thread JIS B2351 or BS 5380 port
- Tube to NPTF SAE J476, ANSI B1.20.1.
- Tube to BSPT BS201.
If you don't find your product, please feel free to contact us!
Hydraulic tube fittings Technical info assembly is belowings:
