1. Definition of ORFS studs connector, ORFS male end or ORFS female swivel end is according to SAE J1453 and ISO 8434-3 standards, Stud end is depended on matched port styles such as Metric ports, BSPP ports, Taper thread ports.
2. Methods of stud connector as DIN Fittings Port Styles showed, please click the link. Styles connect as following: Tube to Metric Port ISO 9974 (DIN 3853) and ISO 6149; Tube to BSPP Port ISO 1179, Tube to UNF port ISO SAE J1926 (ISO 11926), Tube to Japanese BSPP port JIS B2351; Tube to NPT Port ANSI/ASME B 1.20.1; Tube to BSPT Port ISO 7/BS 21/DIN 2999-1.
Dimensions of Metric O-ring Boss Port ISO 6149
1. Male Stud Connector Straight 1FB-WD
ORFS tube end/ BSPP ED
2. Male Stud Connector Straight 1FG
ORFS connector/ BSPP o-ring+Retaining Ring
3. Male Long Stud Connector Straight 1FG-L
ORFS connector/ BSPP o-ring+Retaining Ring
4. Male Stud Connector Straight MOR
ORFS connector/ male stud ISO6149-2 OR
5. Male Stud Connector Straight ORFS MED
ORFS connector/ Metric port ED sealing
6. Male Stud Connector Straight NPT
ORFS connector/ NPT sealing
7. Male Stud Connector Straight ORB
ORFS connector/ SAE ORB ISO 11926-2 port
8. Male Stud Connector Straight BSPT
ORFS connector/ Male BSPT
