SAE J846_201511 is Coding Systems for Identification of Fluid Conductors and Connectors fittings.
SAE J846 is being revised to add identification codes for SAE J534 lubrication (grease) fittings, SAE J518-3 two-bolt flanges, SAE J518-4 and SAE J518-5 flange adapter blocks, and SAE J1926-4 heavy duty Straight Thread O-Ring plugs.
SAE J846 fittings reference standards as follows:
SAE J246 Spherical and Flanged Sleeve (Compression) Tube Fittings
SAE J512 Automotive Tube Fittings
SAE J513 Refrigeration Tube Fittings - General Specifications
SAE J514 Hydraulic Tube Fittings
SAE J515 Specification for Hydraulic O-Ring Materials Used with Hydraulic Connections
SAE J516 Hydraulic Hose Fittings
SAE J517 Hydraulic Hose
SAE J518-1 Hydraulic Flanged Tube, Pipe, and Hose Connections, Four-Screw Flange Connection Part 1: 3.5 MPa to 35 MPa (Code 61)
SAE J518-2 Hydraulic Flanged Tube, Pipe, and Hose Connections, Four-Screw Flange Connection Part 1: 42 MPa (Code 62)
SAE J518-3 Hydraulic Flange Clamps, 2-Screw Connection to be used with J518-1 (Code 61) Connections where only low pressure is required
SAE J518-4 In-line, Elbow, and Tee Flanged Connectors for use with SAE J518-1/ISO6162-1 Components
SAE J518-5 In-line, Elbow, and Tee Flanged Connectors for use with SAE J518-2/ISO6162-2 Components
SAE J530 Automotive Pipe Fittings
SAE J531 Automotive Pipe, Filler, and Drain Plugs
SAE J532 Automotive Straight Thread Filler and Drain Plugs
SAE J534 Lubrication Fittings
SAE J1231 Formed Tube Ends for Hose Connections and Hose Fittings
SAE J1453-1 Specification for O-Ring Face Seal Connectors: Part 1 - Tube Connection Details and Common Requirements for Performance and Tests
SAE J1453-2 Specification for O-Ring Face Seal Connectors: Part 2 - Requirements, Dimensions, and Tests for Steel Unions, Bulkheads, Swivels, Braze Sleeves, Caps, and Connectors with ISO 6149-2 Metric Stud Ends
SAE J1453-3 Specification for O-Ring Face Seal Connectors: Part 3 - Requirements, Dimensions, and Tests for Steel Unions, Bulkheads, Swivels, Braze Sleeves, Caps, and Connectors with SAE J1926-2 Inch Stud Ends
SAE J1926-1 Connections for General Use and Fluid Power - Ports and Stud Ends with ASME B1.1 Threads and O-Ring Sealing - Part 1: Threaded Port with O-Ring Seal in Truncated Housing
SAE J1926-2 Connections for General Use and Fluid Power - Ports and Stud Ends with ASME B1.1 Threads and O-Ring Sealing - Part 2: Heavy-Duty (S Series) Stud Ends
SAE J1926-3 Connections for General Use and Fluid Power - Ports and Stud Ends with ASME B1.1 Threads and O-Ring Sealing - Part 3: Light-Duty (L Series) Stud Ends
SAE J1926-4 Connections for General Use and Fluid Power - Ports and Stud Ends with ASME B1.1 Threads and O-Ring Sealing - Part 4: External Hex and Internal Hex Inch Port Plugs – Dimensions, Design, Test Methods and Requirements
SAE J2494-1 Dimensional Specifications for Metallic Body Push-to-Connect Fittings Used on a Vehicle Air Brake System
SAE J2494-2 Dimensional Specifications for Non-Metallic Body Push-to-Connect Fittings Used on a Vehicular Air Brake System
SAE J2552 Push-On Hose and Mating Hose Fittings
