Eaton field attachable fittings is used to connect different type of hose, with low pressure air, lube, fuel line, oil lines, hydraulic application and suction return lines, air brake hose line, Generally used for automotive, light truck, and small engine fuel lines; Medium pressure and high temperature hose lines for a variety of applications including heavy-duty truck, industrial, and small engine where temperature may be a problem, construction, farm implement and industrial equipment.High pressure hydraulic applications such as construction, farm implement and industrial equipment. Field attachable hose fittings is also know as reusable hydraulic fittings.
Pressure of reusable hose fittings is determined by maximum working pressure for hose size, material is available in AISI 1020, 1045 carbon steel, CA360 brass, stainless steel 314, 316 and 316L.
Eaton new catalog of hose end for field attachable, it is designed without crimper assembly, they are a sustainable option and flexible fit for many applications and hose styles, including socketless, braided, spiral and PTFE etc.
Types of field attachable hose fittings used in different application as follows:
Reusable Hose End 009 'B' Series fittings for Low pressure air, lube and oil hose lines.Advantages: Reusable and easy to assemble. An excellent fitting where low pressure applications exist and a clamp may get in the way. Good selection of configurations at a reasonable cost.
Assembly Instructions: 1. Lubricate insert threads and I.D. of hose. 2. Push hose into socket until it bottoms. 3. Screw insert into socket until insert hex touches socket. When assembling swivel ends, leave 1/32" clearance between swivel nut and socket. Pipe fitting connect type is Swivel nuts are universal both SAE 37°and 45° connections.
Hose bead End 057 ‘B’ Series fittings is for Low pressure air, fuel and oil applications. Generally used for automotive, light truck, and small engine fuel lines. Port connection types including SAE 45° Flare Connector, Inverted Male Connector and SAE ORB connector.
Assembly Instructions: 1. Slide clamp over hose. 2. Insert barbed end of fitting into hose. 3. Locate band clamp in the middle of 057 'B' Series inserts and tighten. 4. Position wire clamp behind bump on 057 'B' Series insert with H057 hose only.
Hose End 100 'B' Series barbed push on fittings is for Low pressure shop or service air lines. Often used for low pressure lube and oil lines. Port connection types including SAE 45° Flare Connector, Inverted Male swivel Connector, Female Inverted Rigid, JIC 37°Female Swivel, SAE 45° Flare Female Swivel and SAE ORB connector.
Hose End 105 ‘B' Series barb fittings is for Low pressure shop or service air lines. Push on hose fittings and Locate clamp in middle of insert and tighten for sealing. Port connection fittings type including male NPTF, female NPTF.
Hose End 338 ‘B’ Series reusable fittings is for Air brake hose lines.Can be used for nearly any air brake line. Easy to assemble with a good selection of hose end configurations. Brass material offers excellent resistance against corrosion.
Hose End 069 'D' Series reusable fittings is for Medium pressure and high temperature hose lines for a variety of applications including truck, industrial, and small engine where temperature may be a problem. Port fitting connection types including JIC 37°Female Swivel, SAE 45°Female Swivel, 30°Flare Female Swivel.
Hose End 'K' Series suction reusable fittings is for Low pressure hydraulic applications and suction lines. Push hose on barbed stand pipe. Be sure hose is bottomed to clamp retainer assembly.
Hose End 039 'K' Series suction fittings is for Suction and return lines; Used with suction hose for suction or return lines. For low pressure applications. Slide clamps onto hose assembly.
Hose End 104 'N' Series reusable hydraulic fittings is for Medium pressure hydraulic applications such as construction, farm implement and industrial equipment. Advantage is Good selection
of hose ends. Non-mandrel assembly. Wide variety of applications.
Hose End 213 'N' Series reusable fittings is for Medium pressure and high temperature hose lines for a variety of applications including truck, industrial, and small engines where high temperatures exist.
Hose End 247 'N' Series reusable fittings is for Medium pressure and high temperature hose lines for a variety of applications including truck, industrial, and small engine where temperature may be a problem.
Hose End 425 'N' Series field attachable reusable fittings is for High pressure hydraulic applications such as construction, farm implement and industrial equipment.
Hose End 436 'N' Series reusable hose fittings is for Medium pressure hydraulic applications where compatibility may be a problem or where shock hazards exist.
