BSPP 60 degree cone to BSPT pipe fitting branch tee connector.
Material is forged carbon steel or stainless steel.
OEM and ODM size is also available.
ABTB-SP BSP MALE/BSPT MALE/BSP MALE pipe connector size chart as follow:
PART NO. | THREAD | DIMENSIONS | ||||||
E | F | G | A | B | C | S1 | ||
ABTB-02SP | G1/8"X28 | R1/8"X28 | G1/8"X28 | 19.8 | 21 | 19.8 | 11 | |
ABTB-04SP | G1/4"X19 | R1/4"X19 | G1/4"X19 | 24.5 | 25.5 | 24.5 | 14 | |
ABTB-06SP | G3/8"X19 | R3/8"X19 | G3/8"X19 | 27.5 | 28.5 | 27.5 | 16 | |
ABTB-08SP | G1/2"X14 | R1/2"X14 | G1/2"X14 | 34.5 | 36 | 34.5 | 22 | |
ABTB-12SP | G3/4"X14 | R3/4"X14 | G3/4"X14 | 40 | 43.5 | 40 | 27 | |
ABTB-16SP | G1"X11 | R1"X11 | G1"X11 | 46 | 50 | 46 | 33 | |
