BSP pipe fittings dimensions and catalogue is the same from different suppliers.
Material Types of pipe fittings such as stainless steel, brass and plastic.
UK and USA BSPP thread pipe fittings application in instrumentation pipe fittings and industrial pipe fittings.
BSP pipe ftting adaptors to socket weld, NPT male, SAE ORB, BSPT male, ORFS male, DIN 2353 tube connector, metric o-ring etc.
Shape of BSPP pipe adaptor such as straight, Elbow, Tee, Cross,Reducer.
We also can supply up to 2 inch bsp fittings.
5TB-SP BSPT MALE/BSP FEMALE pipe connector size chart as follow:
PART NO. | THREAD | DIMENSIONS | |||||
E | F | A | L | S1 | |||
5TB-02-04SP | R1/8"X28 | G1/4"X19 | 10 | 31.5 | 19 | ||
5TB-04-06SP | R1/4"X19 | G3/8"X19 | 14.5 | 38.5 | 22 | ||
5TB-04SP | R1/4"X19 | G1/4"X19 | 14.5 | 35 | 19 | ||
5TB-06-04SP | R3/8"X19 | G1/4"X19 | 15 | 36 | 19 | ||
5TB-06-08SP | R3/8"X19 | G1/2"X14 | 15 | 43 | 27 | ||
5TB-06-12SP | R3/8"X19 | G3/4"X14 | 15 | 44 | 36 | ||
5TB-06SP | R3/8"X19 | G3/8"X19 | 15 | 39 | 22 | ||
5TB-08-06SP | R1/2"X14 | G3/8"X19 | 20 | 44 | 22 | ||
5TB-08-12SP | R1/2"X14 | G3/4"X14 | 20 | 50 | 36 | ||
5TB-08-16SP | R1/2"X14 | G1"X11 | 20 | 54.5 | 41 | ||
5TB-08SP | R1/2"X14 | G1/2"X14 | 20 | 48 | 27 | ||
5TB-12-08SP | R3/4"X14 | G1/2"X14 | 20 | 48 | 30 | ||
5TB-12-16SP | R3/4"X14 | G1"X11 | 20 | 54.5 | 41 | ||
5TB-12SP | R3/4"X14 | G3/4"X14 | 20 | 49 | 36 | ||
5TB-16-12SP | R1"X11 | G3/4"X14 | 25.5 | 55 | 36 | ||
5TB-16-20SP | R1"X11 | G1.1/4"X11 | 25.5 | 61.5 | 50 | ||
5TB-16SP | R1"X11 | G1"X11 | 25.5 | 60 | 41 | ||
5TB-20-08SP | R1.1/4"X11 | G1/2"X14 | 26.5 | 39 | 46 | ||
5TB-20-12SP | R1.1/4"X11 | G3/4"X14 | 26.5 | 39 | 46 | ||
5TB-20-24SP | R1.1/4"X11 | G1.1/2"X11 | 26.5 | 63 | 55 | ||
5TB-20SP | R1.1/4"X11 | G1.1/4"X11 | 26.5 | 61.5 | 50 | ||
5TB-24-16SP | R1.1/2"X11 | G1"X11 | 26.5 | 40.5 | 55 | ||
5TB-24-20SP | R1.1/2"X11 | G1.1/4"X11 | 26.5 | 61 | 55 | ||
5TB-24-32SP | R1.1/2"X11 | G2"X11 | 26.5 | 63.5 | 70 | ||
5TB-24SP | R1.1/2"X11 | G1.1/2"X11 | 26.5 | 63 | 55 | ||
5TB-32-24SP | R2"X11 | G1.1/2"X11 | 30 | 45 | 65 | ||
