A reusable hose fitting for connecting a hose to an accessory including a nipple fixedly connected at one end to the accessory and having a sleeve removably inserted into the open end of the hose.
HYDRAULIC 22618-R5T BSPP FEMALE 60°CONE
| PART NO. | THREAD E | HOSE BORE | DIMENSIONS | ||
| DN | DASH | C | S2 | ||
| 22618-04-04(R5T) | G1/4"X19 | 5 | 04 | 5.5 | 19 |
| 22618-06-05(R5T) | G3/8"X19 | 6 | 05 | 6.3 | 22 |
| 22618-06-06(R5T) | G3/8"X19 | 8 | 06 | 6.3 | 22 |
| 22618-08-08(R5T) | G1/2"X14 | 11 | 08 | 7.5 | 27 |
| 22618-10-10(R5T) | G5/8"X14 | 13 | 10 | 9.5 | 30 |
| 22618-12-12(R5T) | G3/4"X14 | 16 | 12 | 10.9 | 32 |
| 22618-16-16(R5T) | G1"X11 | 22 | 16 | 11.7 | 41 |
| 22618-20-20(R5T) | G1.1/4"X11 | 28 | 20 | 11 | 50 |
| 22618-24-24(R5T) | G1.1/2"X11 | 35 | 24 | 13 | 55 |
