Finish: Zinc plate, Zn-Ni plated, Cr6 plated
Optional materials Steel / carbon steel / brass
Port of Loading: Ningbo
Minimum order quantity: 100
Customized service: We specialize in the production of all kinds of hydraulic oil pipes, adjusters, stoves, straws, accessories.
Model: 20518-R5T
PART NO. | THREADE | HOSE BORE | 尺寸DIMENSIONS | ||
| DN | DASH | c | s2 | ||
| 20518-16-04(R5T) | M14X1.5 | 5 | 4 | 1.8 | 19 |
| 20518-16-05(R5T) | M16×1.5 | 6 | 5 | 1.8 | 19 |
| 20518-18-04(R5T) | M18×1.5 | 5 | 4 | 1.5 | 22 |
| 20518-18-06(R5T) | M18×1.5 | 8 | 6 | 1.5 | 22 |
| 20518-20-O6(R5T) | M20×1.5 | 8 | 6 | 2.5 | 24 |
| 20518-22-06(R5T) | M22x1.5 | 8 | 6 | 3 | 27 |
| 20518-24-08(R5T) | M24X1.5 | 11 | 8 | 3 | 30 |
| 20518-30-10(R5T) | M30X2 | 13 | 10 | 2.5 | 36 |
| 20518-30-12(R5T) | M3OX2 | 16 | 12 | 2.5 | 36 |
| 20518-36-12(R5T) | M36×2 | 16 | 12 | 3.2 | 46 |
| 20518-36-16(R5T) | M36×2 | 22 | 16 | 3.2 | 46 |
| 20518-42-16(R5T) | M42x2 | 22 | 16 | 3.9 | 50 |
| 20518-42-20(R5T) | M42×2 | 28 | 20 | 3.9 | 50 |
| 20518-52-20(R5T) | M52X2 | 28 | 20 | 4.5 | 60 |
| 20518-52-24(R5T) | M52X2 | 35 | 24 | 4.5 | 60 |
