ISO 8434-5 pdf standard specifies test methods for threaded hydraulic fluid power connections fittings, including metallic tube fittings connection and stud end fittings of ports.
ISO 8434-5 general requirements as follows:
Test samples
Test temperature
Test report
Proof pressure test including principle, test equipment, procedure, re-use of components.
Failure pressure test(burst)
Cyclic endurance test
Vacuum test
Overtorque test
