Metric 60°Cone DIN 7631
The male connector has a 60° recessed cone and a straight thread; the female has a straight thread as well, and a globeseal seat. The seal forms between the recessed cone on the male and the tapered nose of the female. The threads of both halves mesh to form a strong mechanical bond. This connection is common in hydraulic systems.
Pipe/Tube O.D. (mm) | Metric Thread Size | Male Thread O.D. (mm) | Female Thread I.D (mm) |
6 | M12 x 1.5 | 12 | 10.5 |
8 | M14 x 1.5 | 14 | 12.5 |
10 | M16 x 1.5 | 16 | 14.5 |
12 | M18 x 1.5 | 18 | 16.5 |
15 | M22 x 1.5 | 22 | 20.5 |
18 | M26 x 1.5 | 26 | 24.5 |
22 | M30 x 1.5 | 30 | 28.5 |
28 | M38 x 1.5 | 38 | 36.5 |
35 | M45 x 1.5 | 45 | 43.5 |
52 | M52 x 1.5 | 52 | 50.5 |
