Straight JIC Male To Socket Weld

E

WELD TUBE O.D  D

A

L

S1

5JW-04IN

7/16"X20

1/4"

14

23

14

5JW-04-05IN

7/16"X20

5/16"

14

23

14

5JW-05IN

1/2"X20

5/16"

14

23

14

5JW-06IN

9/16"X18

3/8"

14.1

24

17

5JW-08IN

3/4"X16

1/2"

16.7

29.5

22

5JW-08-06IN

3/4"X16

3/8"

16.7

29.5

22

5JW-08-10IN

3/4"X16

5/8"

16.7

29.5

24

5JW-08-12IN

3/4"X16

3/4"

16.7

29.5

24

5JW-10IN

7/8"X14

5/8"

19.3

32

24

5JW-10-08IN

7/8"X14

1/2"

19.3

32

24

5JW-10-12IN

7/8"X14

3/4"

19.3

35

30

5JW-12IN

1.1/16"X12

3/4"

22

38

30

5JW-12-08IN

1.1/16"X12

1/2"

22

37

30

5JW-12-10IN

1.1/16"X12

5/8"

22

37

30

5JW-12-16IN

1.1/16"X12

1"

22

39

36

5JW-14IN

1.3/16"X12

7/8"

22.6

39.5

36

5JW-16IN

1.5/16"X12

1"

23

40

36

5JW-16-20IN

1.5/16"X12

1.1/4"

23

41

41

5JW-20IN

1.5/8"X12

1.1/4"

24.3

43

46

5JW-20-16IN

1.5/8"X12

1"

24.3

43

46

5JW-20-24IN

1.5/8"X12

1.1/2"

24.3

45.5

50

5JW-24IN

1.7/8"X12

1.1/2"

27.5

48.5

50

5JW-24-20IN

1.7/8"X12

1.1/4"

27.5

48.5

50

5JW-32IN

2.1/2"X12

2"

33.9

55

65

D                                                            NB200   NB500

NB200   NB300          Nut and sleeve should be ordered separately.The nut NB200 and sleeve NB500 is suitable for metric tube,the nut NB200 and sleeve NB300 is suitable for inch tube.
