ORFS swivel fittings size chart types is according to SAE J1453 or ISO 8484-3, ORFS swivel hydraulic fitting types as follows:
a) Swivel elbow (SWE)
b) Swivel branch tee (SWBT)
c) Swivel run tee
a Method of attachment of swivel nut is as chosen by the manufacturer.
b Dimension L 19 and the overall length of the nut are optional with the manufacturer as long as L 20 is maintained and the connector’s performance requirements are met.
c Nut shown in pulled back position. Pullback not required for hose fittings.
