BSPP Union fittings is forged cabon steel body, surface is white or color zinc plated.
Meet BS 5200 standard or ISO 8434-6 fitting requirement, we also can offer OEM size and ODM.
ZB BSP FEMALE pipe connector size chart as follow:
PART NO. | THREAD | DIMENSIONS | |
E F | A,B,C,D | S1 | |
ZB-02 | G1/8"X28 | 20 | 16 |
ZB-04 | G1/4"X19 | 22.5 | 19 |
ZB-06 | G3/8"X19 | 26 | 24 |
ZB-08 | G1/2"X14 | 32 | 30 |
ZB-12 | G3/4"X14 | 34 | 33 |
ZB-16 | G1"X11 | 42 | 41 |
ZB-20 | G1.1/4"X11 | 48 | 50 |
ZB-24 | G1.1/2"X11 | 53 | 60 |
ZB-32 | G2"X11 | 62 | 70 |
