SAE Split Flange hydraulic plugs and caps system
Hydraulic split flange plugs and caps is used in sae flange block port and flange head adapters. Therer are code 61 and code 62 flange working pressure system. These types of SAE flange fittings are most commonly used in the construction equipment market.
Split flange port plugs are designed for pressure and leak testing components, and used in permanent application when SAE flange block port needs to be capped off under full system pressure. SAE flange plug is according to ISO 6162 and SAE J518 standards, but Caterpillar style split flange plugs is difference.
hydraulic flange cap kit has two types: 1. is polyethylene caps to protect the face of fsplit flange head connector or hose fittings; 2 is flange lock tool kit, it is designed and made of lightweight aluminum, to protect your hydraulic systems with flange head connector. Offer a leakproof and enviromental cleanliness aftor disassembling the hydraulic connections, by simple sealing of SAE code 61 and code 62 hydraulic flange fttings.
Code 61 split flange plug
Code 62 split flange plug
Hydraulic flange plug
PART NO. |
FLANGE SIZE | DIMENSIONS | |||
d1 | d2 | L | I | ||
4FL-08 | 1/2" | 30.2 | 24 | 16 | 6.8 |
4FL-12 | 3/4" | 38.1 | 31.5 | 17 | 6.8 |
4FL-16 | 1" | 44.4 | 38 | 17 | 8 |
4FL-20 | 1.1/4" | 50.8 | 43 | 17 | 8 |
4FL-24 | 1.1/2" | 60.3 | 50 | 19 | 8 |
4FL-32 | 2" | 71.4 | 62 | 19 | 9.6 |
4FL-40 | 2.1/2" | 84.1 | 74 | 40 | 9.6 |
4FL-48 | 3" | 101.6 | 90 | 45 | 9.6 |
4FL-56 | 3.1/2" | 114.3 | 102 | 30 | 11.3 |
4FL-64 | 4" | 127 | 114 | 36 | 11.3 |
4FL-80 | 5" | 152.4 | 140 | 45 | 11.3 |
4FS-08 | 1/2" | 31.8 | 24 | 18 | 7.8 |
4FS-12 | 3/4" | 41.3 | 32 | 18 | 8.8 |
4FS-16 | 1" | 47.6 | 38 | 18 | 9.5 |
4FS-20 | 1.1/4" | 54 | 44 | 18 | 10.3 |
4FS-24 | 1.1/2" | 63.5 | 51 | 20 | 12.6 |
4FS-32 | 2" | 79.4 | 67 | 30 | 12.6 |
SAE Flange Plug assembly usage as follows
