BSP 60 cone fittings dimension is according to ISO 8434 6 catalogue, including the details of end for male connector; Details of swivel female end with O-ring sealing nipple (style A); Details of end for swivel female connector (style B).
BSP_60_cone_fittings_dimension_ISO_8434_6_male
BSP_60_cone_fittings_dimension_ISO_8434_6_swivel_female_A
BSP_60_cone_fittings_dimension_ISO_8434_6_swivel_female_B
Use the following statement in test reports, catalogues and sales literature when electing to comply with this part of ISO 8434: "Dimensions and design for 60° cone connectors in accordance with ISO 8434-6, Metallic tube connections for fluid
power and general use — Part 6: 60° cone connectors with or without O-ring."
